Dial® DCS-1 Concentric Cooler Pump 115Vac, 8,500 CFM, 310 GPH

Item
1016
  • California Prop 65

FEATURES & BENEFITS

• Horsepower: 1/60
• Voltage: 115Vac
• Amperage: 0.9
• Connection Size: 1/2 in. & 5/8 in.
• Up to 8,500 CFM
• Up to 310 Gallons per Hour
• Flame Retardant Motor Housing
• Auto Reset Thermal Overload
• 4-1/2 ft. Power Cord
• 3 Prong Grounded Power Cord
• Shock Resistant Motor Housing
• Long Life Technology Bearing and Shaft
• Low Level / Low Recovery
• 1/2" To 4" Water Reservoir Depths
• Elbow Extension w / Elevated Bleed Port
• Built-in Barbed Elbow
• Screened Water Inlet
• Fits All Coolers
• UL Recognized Component and UL Classified Retrofit Pump

Electrical
Voltage 115
Safety Standards
California Prop 65 Yes
Specification
Gallons Per Hour 310 @ 1 ft. Head Height
Maximum CFM 8,500
Weights and Dimensions
Operating Weight (lbs) 2.292
Exterior Dimensions (D) (inches) 4.000000
Exterior Dimensions (W) (inches) 4.000000
Exterior Dimensions (H) (inches) 8.200000
Shipping Weight (lbs) 5.000000
