PRODUCT SPECIFICATIONS
CONSTRUCTION Extruded
TUBE MATERIAL Polyethylene
COLOR Black
DASH SIZE -4
WORKING TEMPERATURE – MIN -40 °F
WORKING PRESSURE 36 bar
PACKAGE FORM Cut length
OUTSIDE DIAMETER .25 in
INSIDE DIAMETER .17 in
TUBE WALL THICKNESS .04 in
BEND RADIUS – MIN .75 in
APPLICATION Pneumatic instrumentation lines, low pressure hydraulic or pneumatic supply lines, process sampling lines, process lines, high moisture content environments.
WORKING TEMPERATURE – MAX 176 °F
| Safety Standards | |
|---|---|
| California Prop 65 | Yes |
| Weights and Dimensions | |
|---|---|
| Operating Weight (lbs) | 14.2 | Exterior Dimensions (D) (inches) | 15.250000 | Exterior Dimensions (W) (inches) | 15.250000 | Exterior Dimensions (H) (inches) | 12.500000 | Shipping Weight (lbs) | 15.000000 |
| Warranty | |
|---|---|
| Country of Origin | United States | Hazardous Material | No |
