Carrier® Solid-State Time Guard II Accessory

FEATURES

The accessory Time Guard II device is used on constant volume units to prevent compressor from short cycling by providing a 5-minute delay before restarting a compressor after shutdown for any reason. One Time Guard II device is required per compressor. On normal start-up, the 5-minute delay occurs before the thermostat closes. After the thermostat closes, the Time Guard II device then has a 3-second delay prior to contactor closure.

INCLUDES

• 1 Time Guard II Device
• 4 No. 8 x 3/4 in. Screws
• 1 No. 8 x 1 in. Screw
• 2 No. 10 x 1/2 in. Screws
• 1 Mounting Bracket
• 1 Brown Wire [24 in. (610mm)]
• 1 Brown Wire [15 in. (381mm)]
• 1 Brown Wire [12 in. (305mm)]
• 1 Violet Wire [24 in. (610mm)]
• 1 Blue Wire [9 in. (229mm)]
• 1 Yellow Wire [21 in. (533mm)]
• 1 Black Wire [21 in. (533mm)]
