Reflectix® Duct Insulation is an alternative to other types of fibrous insulation products. Ease of handling and quick installation make Reflectix ® the first choice when selecting insulation for round or rectangular ductwork in HVAC systems.
FEATURES & BENEFITS
• Reflectix® Duct Insulation consists of two layers of highly reflective film (96% reflectivity) that are bonded to two tough layers of polyethylene. Two inner layers of insulating bubbles resist conductive heat flow while a center layer of polyethylene gives Reflectix ® high reliability and strength. The product has a tape running the length of the roll for easy identification by code officials. The tape identifies the manufacturer and ASTM Testing: Reflectix ® Duct Insulation ASTM E84, Class A / Class 1, ASTM C411 Passed • Non-toxic / non-carcinogenic • Not affected by moisture or humidity • Fiber-free • Does not promote nesting of birds, insects or rodents • Resists growth of fungi, mold, mildew • Does not require protective clothing or respirators to install • Costs less to install • Lowers heating and cooling costs year-round • Lightweight and clean • ISO 9001:2015 Certified Manufacturing Location • Temperature Range: -30 0 to +180 0 F • Nominal Thickness: 5/16 inch (.312) • Weight: 0.771 oz./sq. ft. • Flame Spread Index (ASTM E 84): Less than 25 • Smoke Developed Index (ASTM E 84): Less than 50 • Mounting Method (ASTM E 2599) • Fire Rating: Class A/Class 1 • Linear Shrinkage: None • Reflectance (IR): 96% • Water Vapor Transmission (ASTM E 96): 0.02 • Puncture Resistance: 60 lb./in. • Mold and Mildew: No Growth • Emittance: 0.04 • Tensile Strength: 3.7 N/mm • Pliability: No Cracking • Hot Surface Performance: Passed (250 0 F) • Note: Not for use in direct contact on surface temperatures that are 180 0 F or greater.
