Control Voltage Adapter Kit
Item
KAAVC0101AAA
FEATURES
The kit is designed to allow communication between specific indoor and outdoor units that otherwise would not be compatible. The kit is compatible with 208/230V high wall ductless indoor units and 208/230/460V horizontal discharge outdoor units with single phase or three phase power at 60Hz.
The KAAVC0101AAA Kit converts high-voltage control signals from a high wall indoor unit into low-voltage control signals for a horizontal outdoor unit. In cooling only systems, the kit carries the compressor control signal.
INCLUDES
• 1 One KAAVC0101AAA Control Voltage Adapter Kit• 2 Two 1/4 inch Phillips Mounting Screws
• 1 Installation Instructions
• 1 Wire Ties
• 1 Electrical Shock Hazard Warning Label
• 1 Wiring Diagram Label
• 1 Label Cover
| Safety Standards | |
|---|---|
| California Prop 65 | Yes |
| Weights and Dimensions | |
|---|---|
| Operating Weight (lbs) | 17.6 | Exterior Dimensions (D) (inches) | 26.300000 | Exterior Dimensions (W) (inches) | 9.700000 | Exterior Dimensions (H) (inches) | 15.100000 | Shipping Weight (lbs) | 18.000000 |
