FEATURES & BENEFITS
• User adjustable temperature setting
• SPDT switch
• UL® Recognized
• N.O. Contacts: 125VA at 120 and 240VAC
• N.C. Contacts: 2.9FLA, 17.4LRA at 240VAC
• N.C. Contacts: 5.8FLA, 34.8LRA at 120VAC
• Pilot Duty NC Contact: 40VA at 30, 120 and 240VAC
• Fixed differential: 30 °F
• Limit temp. Range: 150 °F to 250 °F
• Length: 3"
| Safety Standards |
| California Prop 65 |
Yes |
| Weights and Dimensions |
| Operating Weight (lbs) |
3 |
Exterior Dimensions (D) (inches) |
8.000000 |
Exterior Dimensions (W) (inches) |
4.000000 |
Exterior Dimensions (H) (inches) |
3.000000 |
Shipping Weight (lbs) |
3.000000 |
