i-Vu® Building Automation Network Device, (485 Networks)
Item
PROT485
OVERVIEW
Network Device
Carrier's ancillary network devices ensure optimum performance for BACnet MS/TP and other EIA-485 networks. These devices install easily and work together to amplify data signals and provide surge protection, bias and termination to any EIA-485 network.
FEATURES
FEATURES & BENEFITS
Key Features & Benefits
The PROT485 provides electrical surge protection to controllers installed within 250ft. (76m)
SPECIFICATIONS
| Power | n/a |
| Mounting | 4" Snap Track |
| Terminals | Removable screw terminals |
| Network Requirement | At each place wire enters or exits the building, or for maximum protection, 1 recommended within 250 ft. (76m) of each controller. |
| Network Wiring | 22/24 AWG, single twisted shielded pair, low capacitance, CL2P wire |
| Protection | 2 replaceable 0.5 A fuses protect the Fused connection: F1, type 3AG, 250 Vac, 0.5 A, T (time-lag) F2, type 3AG, 250 Vac, 0.5 A, T (time-lag) |
| Operating Temperature | -20° to 140°F (-29° to 60°C), 10-90% relative humidity, non-condensing |
| Listed by | UL-916 (PAZX), cUL-916 (PAZX7), CE EN50082-1997 |
| Dimensions | 4" (width) by 4" (height) by 2" (depth) / 102mm (width) by 102mm (height) by 51mm (depth) |
| Safety Standards | |
|---|---|
| California Prop 65 | Yes |
| Weights and Dimensions | |
|---|---|
| Operating Weight (lbs) | 1 | Exterior Dimensions (D) (inches) | 6.000000 | Exterior Dimensions (W) (inches) | 3.000000 | Exterior Dimensions (H) (inches) | 1.000000 | Shipping Weight (lbs) | 3.000000 |
| Warranty | |
|---|---|
| Hazardous Material | No |
