Carrier Toshiba 24,000 BTU Cassette Fan Coil, 208/1
Whether you're supplementing cooling and heating in an entry or an interior room, you'll appreciate the power and efficiency of this in-ceiling Cassette unit.
If your need is for comfort, features like three indoor fan speeds and fixed or oscillating louver control will make an impression.
The RAVUT Cassette indoor unit is matched with the RAVAT heat pump to create the RAV Ductless Light Commercial system.
STANDARD FEATURES
- Available in 208/230V
- Modes: Cool, Heat, Dry, Fan, Auto
- Three indoor unit fan speeds
- Built-in condensate pump
- Branch duct capability
- Outside air intake
- Sleep Mode
- Power Saving Mode
- Independent louver control (fixed or swing)
- Quiet indoor sound operation, as low as 32 decibels1
- Washable filter with on-unit filter maintenance indicator
- System diagnostics
- 10-year parts limited and 10-year compressor limited warranties to the original purchasing owner upon timely registration2
CONTROL STANDARD FEATURES
- Optional Wireless Remote Controller
- Optional Wired Remote Controller (Convertible)
OPTIONAL FEATURES
- Outside air intake
- Air discharge direction kit
1 Quietest size within each model group during low fan-speed operation
2 If properly registered within ninety (90) days after original installation, parts are warranted to the original purchaser for a period of 10 years. Otherwise, parts warranty is 5 years. For other applications a 7-year parts and 7-year compressor limited warranties apply. See warranty certificate for details.
Electrical | |
---|---|
Hertz | 60 | Phase | 1 | Voltage | 208/230 |
Safety Standards | |
---|---|
California Prop 65 | Yes |
Specification | |
---|---|
Sound Level | 39 | SEER | 20.7 | HSPF | 9.5 |
Weights and Dimensions | |
---|---|
Operating Weight (lbs) | 44 | Exterior Dimensions (D) (inches) | 33.100000 | Exterior Dimensions (W) (inches) | 33.100000 | Exterior Dimensions (H) (inches) | 10.100000 | Shipping Weight (lbs) | 74.000000 |
