Totaline® Delay-On-Make Timer, Adjustable (0 to 10 Min.)

APPLICATIONS

Helps to protect air conditioning, refrigeration and heat pump equipment from damage which may be caused by the rapid short-cycling of compressor.

FEATURES & BENEFITS

• Universal voltage operation.
• Higher 1.5 amp power rating.
• Knob-adjustable time delays.
• Work with anticipator-type thermostats.
• One model replaces many in field. Ideal for compressor staging.
• Simple 2-wire hookup.
• Compact 2” x 2” package.
• Input: 18-240 VAC, 1.5 amps, 15 amp inrush
• SPST, N.O.
• Adjustable delays: .03-10 min.(1.8-600 sec.)
• Voltage drop: 2.5V @ 1.5 amps

REPLACES

• Diversified: AC-800 fixed volt: ASC-00/601
• Gemline: IC310/ICS213
• Mars: 32391/32367
• Robertshaw: 3310-068
• Supco: TD-68 D-69
• WATSCO: EAC-701-ADJ., X, EAC-700-A
