Toshiba Carrier VRF Rooftop Unit w/Vane Axial Fan
Item
40QQ-E
"36,000 to 60,000 Btuh
"
36,000 to 60,000 Btuh
3.0 to 5.0 tons
The Toshiba Carrier Variable Refrigerant Flow (VRF) rooftop unit with Vane Axial Fan (VAF) technology is ideal for existing rooftop replacement application. Options like electric heat with single-point power connection, horizontal or vertical discharge, economizer and use of existing curb can help make a replacement job go faster and become more cost effective with minimal down time.
Product Features
- Available in 3, 4 & 5 ton capacity
- Unit Power Supply: 208/230-1-60 or 460-3-60
- Direct drive, ECM motor
- Max external static pressure up to 1.2
- Pre painted exterior panels and primer-coated interior panels tested to 500 hour salt spray protection
- Two-inch disposable returns air filters
- Full perimeter base rail with built in rigging adapters for fork trucks slot
- ASHRAE 15 & 34
- Title 24 of the California Code of Regulations
- Light weight compared to standard rooftop unit
- Use existing roof curb
- Increased efficiency
- Unit is shipped with mounting bracket for flow selector box as standard for heat recovery system
- Optional features like electric heat & economizer are available from factory for field installation
Reliability Features
- Finned tube heat exchanger
- Suitable for R410a refrigerant
- All equipment wiring complies with NEC requirements
- Unit constructed in accordance with UL and UL, Canada standards
Installation Features
- Same foot print as installed Carrier 3-5 ton rooftops back to 1989, reducing installation costs and time
- Field convertible from vertical to horizontal airflow for slab mounting
- Unit is shipped with mounting bracket for flow selector box as standard for heat recovery system
- Factory provided controls
- Single point electric connections
| Safety Standards | |
|---|---|
| California Prop 65 | Yes |
| Weights and Dimensions | |
|---|---|
| Operating Weight (lbs) | 1 | Exterior Dimensions (D) (inches) | 1.000000 | Exterior Dimensions (W) (inches) | 1.000000 | Exterior Dimensions (H) (inches) | 1.000000 | Shipping Weight (lbs) | 1.000000 |
